Product features

The RUG series large screen display multifunctional automatic controller is suitable for 12 channels of reactive power control output, with RS-485 communication interface and support for MODBUS communication protocol. It adopts 128x64 Chinese LCD display, AC sampling, harmonic protection, and has three control modes: three-phase, split phase, and comprehensive compensation. It can display and measure the power factor, voltage, current, active power, reactive power, total harmonic distortion rate of each phase in the L1 and L2.3 measurement systems Frequency, time, and reactive power control have protection functions for overvoltage, undervoltage, phase loss, and voltage harmonic exceeding limits. All setting data can be set through backend management software to prevent power loss.
